KuKirin M4 Max Electric Scooter

General Specifications:

• Frame Material: Aluminum alloy + carbon steel

• Unfolded Dimensions: 1180 × 590 × 1295 mm

• Folded Dimensions: 1190 × 590 × 515 mm

• Vehicle Weight: 24 ± 0.5 kg

• Maximum Load Capacity: 120 kg

• Waterproof Level: IP54

⸻
Motor and Battery:

• Motor: Rear hub, 800 W peak, 500 W rated, max RPM 1000 ± 40 rpm

• Maximum Torque: ≥ 27.1 N·m

• Battery Capacity: 48 V, 18.2 Ah (≈ 873 Wh) lithium-ion

• Charging Time: 9–10 hours

• Maximum Range: Up to 64 km per full charge

⸻

Performance:

• Maximum Speed: 45 km/h

• Driving Modes: 3 levels (~15/25/45 km/h)

• Climbing Angle: ≤ 20° incline

⸻

Transmission and Brakes:

• Braking System: Front and rear mechanical disc brakes

• Braking Distance: 6–8 m

⸻

Tires and Suspension:

• Tire Size: 10″ pneumatic (“vacuum”) front and rear

• Suspension: Dual spring suspension (front & rear)

⸻

Display and Lighting:

• Display: Multifunction LCD screen (speed, battery, mode, trip)

• Lighting: LED headlight, taillight, turn signals, side ambient lighting

⸻

Additional Features:

• Folding System: Quick-fold latch for portability

• Seat: Detachable cushion kit

• Cruise Control: Yes

• Horn: Electronic

• Water & Dust Resistance: IP54 rated

• Rated Voltage / Charger Specs: AC 100–240 V, 2.5 A → 54.6 V, 2 A output
